150Kg Wax Melting Machine

Wax Melter Pot Introduction :

GW-0227 INSTANT MELTING BOX. Mainly used to melt wax in the candle production process. This product has automatic temperature control and delayed intermittent heating functions.

It is common for both 3N-380V and 220V power sources. It adopts heat conduction liquid five-sided heating method with high thermal efficiency. The temperature control range is 70C- Adjustable at 300°C.

When the wax liquid temperature reaches the set value, the machine automatically stops heating. When the wax liquid temperature is lower than the set temperature by 4°C, the machine automatically starts heating to achieve the purpose of constant temperature heating.

Wax Melter Pot Features of this machine:

1. Reasonable design, simple structure and low price.

2. Easy to install and easy to operate.

3. High thermal efficiency, safety and reliability.

This machine is used in conjunction with the candle machine produced by our factory, which can save floor space, reduce the number of operators and improve production efficiency.

Wax Melter Pot Technical specifications:

GW-0227 INSTANT MELTING BOX

Volume(L)：180 L

Setting temperature ℃：112 ℃ （70-140 ℃ adjustable）

Capacity: 100KG/hour

Voltager: 3N-380V

Power frequency:50Hz-60Hz

Power(Kw):12Kw

Add reference amount of heat transfer fluid(Kg):50Kg

Name of each part:

1. Melting wax chamber cover

2. Wax melting chamber

3. Power indicator

4. Heating completed indicator

5. Heating indicator

6. Start button

7. Temperature controller

8. Put wax mouth

9. Fuel hole

10. Fuel cap
